MUFFLE FURNACE (1500C)
MUFFLE FURNACE (1700 ºC)
MUFFLE FURNACE (1700 ºC)
MUFFLE FURNACE (1700 ºC)
- Model : CIMF-17/Prog.
- Maximum Temp. : 1700ºC
- Working Temp. : 1600ºC
- Temp. Accuracy : ± 1ºC
- Heating Elements : Molybdenum Didevegsilicide (MoSi2) heating elements, easily replaceable.
- Inner Chamber : Ceramic Brick/Board.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Body & Construction : Made of mild of steel duly Powder Coated/Triple Walled.
- Sensor : Pt / Pt - Rh
- Safety : High Speed Semi Conductor Fuse/Over Current Short Circuit Protection High Temp Alarm.
- Power Supply : 220 volts, single phase AC supply.
MUFFLE FURNACE (1500 ºC)
MUFFLE FURNACE (1700 ºC)
MUFFLE FURNACE (1700 ºC)
- Model : CIMF-15/Prog.
- Maximum Temp. : 1500º C
- Working Temp. : 1400ºC
- Temp. Accuracy : ± 1ºC
- Heating Elements : Silicon Carbide, with end connecon, easily replaceable.
- Inner Chamber : Ceramic Brick/Board.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Body & Construction : Made of mild of steel duly Powder Coated/Triple Walled.
- Sensor : Pt / Pt - Rh
- Safety : High Speed Semi Conductor Fuse/Over Current Short Circuit Protecon High Temp Alarm
- Power Supply : 220 volts, single phase AC supply.
MUFFLE FURNACE (1200 ºC)
MUFFLE FURNACE (1700 ºC)
MUFFLE FURNACE (1200 ºC)
- Model : CIMF-12/Prog.
- Maximum temperature : Upto 1200º C
- Working Temp. Range : Upto 1150º C.
- Temp. Accuracy : Heating Element are made of KANTHAL “A1" Wire.
- Inner Chamber : Ceramic Board/Fiber.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Body & Construction : Made of mild of steel duly Powder Coated/Double Walled.
- Sensor : Cr / Al
- Safety : High Speed Semi Conductor Fuse/Over Current Short Circuit Protection High Temp Alarm
MUFFLE FURNACE (1200 ºC)
vertical split tube furnace (1700c)
MUFFLE FURNACE (1200 ºC)
- Model : CIMF-12/Prog.
- Maximum temperature : Upto 1200º C
- Working Temp. Range : Upto 1150º C.
- Temp. Accuracy : Heating Element are made of KANTHAL “A1" Wire.
- Inner Chamber : Ceramic Board/Fiber.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Body & Construction : Made of mild of steel duly Powder Coated/Double Walled.
- Sensor : Cr / Al
- Safety : High Speed Semi Conductor Fuse/Over Current Short Circuit Protection High Temp Alarm
vertical split tube furnace (1700c)
vertical split tube furnace (1700c)
vertical split tube furnace (1700c)
- Model CIVSTF (1700Prog. /1400Prog. /1200Prog.)
- Maximum Temp. : (1700°C/1400°C/1200°C)
- Working Temp. : (1600°C/1350°C/1150°C)
- Temp. Accuracy : ± 1ºC
- Heating Elements : Molybdenum Disilicide (MoSi2) / Silicon Carbide / KANTHAL “A1" Wire
- Tube Size : as per customer require standard 60x65x1200mm Quds, 58x65x1200mm (alumina)
- Hot zone (200 to 250 to 300mm) standard other with as per customer required hedry zone.
- Power Supply : 220 Volts, single phase AC supply.
- all accessories attachment as per customer required vacuum pump, quarts tube , alumina tube, high purity alumina tube (99.8%), chiller , MFC all tube of gases. vacuum thought rotary or refusion pump up to 10-4 bar rotation of tube, vertical, horizontal, all model and attachment
tube furnace (1700c)
vertical split tube furnace (1700c)
vertical split tube furnace (1700c)
- Model CIVSTF (1700Prog. /1400Prog. /1200Prog.)
- Maximum Temp. : (1700°C/1400°C/1200°C)
- Working Temp. : (1600°C/1350°C/1150°C)
- Temp. Accuracy : ± 1ºC
- Heating Elements : Molybdenum Disilicide (MoSi2) / Silicon Carbide / KANTHAL “A1" Wire
- Tube Size : as per customer require standard 60x65x1200mm Quds, 58x65x1200mm (alumina)
- Hot zone (200 to 250 to 300mm) standard other with as per customer required hedry zone.
- Power Supply : 220 Volts, single phase AC supply.
- all accessories attachment as per customer required vacuum pump, quarts tube , alumina tube, high purity alumina tube (99.8%), chiller , MFC all tube of gases. vacuum thought rotary or refusion pump up to 10-4 bar rotation of tube, vertical, horizontal, all model and attachment
tube furnace (1700ºC)
BOTTOM LOADING FURNACE
BOTTOM LOADING FURNACE
- Model CIVSTF (1700Prog. /1400Prog. /1200Prog.)
- Maximum Temp. : (1700°C/1400°C/1200°C)
- Working Temp. : (1600°C/1350°C/1150°C)
- Temp. Accuracy : ± 1ºC
- Heating Elements : Molybdenum Disilicide (MoSi2) / Silicon Carbide / KANTHAL “A1" Wire
- Tube Size : as per customer require standard 60x65x1200mm Quds, 58x65x1200mm (alumina)
- Hot zone (200 to 250 to 300mm) standard other with as per customer required hedry zone.
- Power Supply : 220 Volts, single phase AC supply.
- all accessories attachment as per customer required vacuum pump, quarts tube , alumina tube, high purity alumina tube (99.8%), chiller , MFC all tube of gases. vacuum thought rotary or refusion pump up to 10-4 bar rotation of tube, vertical, horizontal, all model and attachment
BOTTOM LOADING FURNACE
BOTTOM LOADING FURNACE
BOTTOM LOADING FURNACE
· Maximum temp.: 1500°C
· Working temp.1400°C
· Heating elements: Silicon Carbide Heating Element placed on two sides are easily replaceable.
· Insulation: High Density Ceramic insulation
· Construction: The furnace has opening at the top and bottom. The bottom lid is closed by Motorized lifting, the crucible with the sample can be lifted for heating and lowered by push of a bottom (Motorized)
· Control Panel: Placed on the side of the furnace with all components.
· Temp. Programmer: PID programmer having minimum 1 programs x 16 segments (ramp/soak.)
· Power control:SCR Unit ( Phase angle thyristor )
· Melting capacity: 2-3 kg (aluminum)
· Power supply : 220 volts single phase
ROCKING TUBE FURNACE
BOTTOM LOADING FURNACE
ROCKING TUBE FURNACE
· Maximum temp. 1150°C
· Working Temp.1000°C
· Temp. accuracy :
· Heating Elements : kanthal - A1 wire , coil type wound on the tube.
· Tube tube diameter : alumina
· External Diameter of furnace: 250mm
· Overall Length: 400
· Hot zone length: 200mm
· Rocking angle:
· Insulation: Ceramic fiber
· Temp. control: microprocessor based Programmable (1 prog. X 16 segments) Temp. Controller, with ramp and soak segments. Dual display of set & Actual temp. with soft touch keys. With thermocouple break protections & cold junction compensation.
· Sensor: Cr/ AL
· Safety: over current and short circuit protection, Thermocouple break alarm. High temp. alarm.
· Power control: SSR Unit
Power supply: 220V , 50 hz single phase ac only
CVD SETUP
eight zone tube furnace
ROCKING TUBE FURNACE
Sidable tube furnace with dia 60mm x length 1200mm quartz tube and flange. Maximum temperature up to 1200/ 1400. One pairof sliding rail is installed on bottom of furnace. The furnace can move by motor form one side to the other, to achiever max. Heating and cooling rate up to 100/min. for the fastest heating , you can pre- heat furnace to the desired temperature, then move furnace to sample side, for the fastest cooling, youi may move furnace to another sie after heating sample. It is ideal funace for rapid thermal processing at lowest cost
eight zone tube furnace
eight zone tube furnace
eight zone tube furnace
Maximum Temp.: 1200º C
Working Temp : 1150ºC Temp. Accuracy : ±1ºC Heating Elements: Silicon Carbide, with end connection
MoSi2 MUFFLE FURNACE
eight zone tube furnace
eight zone tube furnace
Model : CIMF-17/Prog.
Maximum Temp.: 1700º C
Working Temp : 1600ºC
Temp. Accuracy : ±1ºC
Heating Elements: Molybdenum Disilicide (MoSi2) heating elements, easily replaceable.
Inner Chamber : Ceramic Brick/Board
Insulation : Ultra High purity alumina low thermal mass insulation.
Body & Construction : Made of mild of steel duly Powder Coated / triple Walled.
Sensor : Pt / Pt - Rh
Safety : High Speed Semi Conductor Fuse / Over Current Short Circuit Protection high Temp Alarm.
Power Supply : 415 volts, Single Phase AC Supply.
Who We Are
STARRING OVEN WITH HEATING
Industrial Three Zone Tube Furnace
STARRING OVEN WITH HEATING
Maximum temperature: up to 250 C
Working Temp. Range: up to 250ºC. Temp. Accuracy: ± 1ºC.
In this system there is one path of circulating Hot Air in- between the inner chamber and insulation. Forced Air Moved by the motorized blower is called PERFECT SYSTEM. It results minimum temperature variation at any point in working space.
Temperatu
Maximum temperature: up to 250 C
Working Temp. Range: up to 250ºC. Temp. Accuracy: ± 1ºC.
In this system there is one path of circulating Hot Air in- between the inner chamber and insulation. Forced Air Moved by the motorized blower is called PERFECT SYSTEM. It results minimum temperature variation at any point in working space.
Temperature controlled by based Microprocessor PID Digital Indicator Cum Controller from 50˚C to 250˚C with a sensitivity of ± 1˚C
Working chamber is made of SS 304 steel and outside made of Mild Steel finished with attractive powder coating with wire mesh nickel plated trays (2No.). To work on 220/230 Volts A.C.
OUTER SIZE
18” x 18” x 18” Inch.
note: size as per buyer requirement
Three Zone Tube Furnace
Industrial Three Zone Tube Furnace
STARRING OVEN WITH HEATING
MAKE: CITY (ISO 9001 – 2015 CERTIFIED CO.)
Technical Specifications:
Maximum Temp.:
Zone 1 = 1200 ºC= (Work. Temp. = 1150 ºC, Heating Elements Silicon Carbide Rods with R type sensor)
Zone 2 = 1200 ºC = (Work. Temp. = 1150 ºC Heating elements Kanthal – A1 wire, Coil type with end connections with k type sensor)
Zone 3 = 1200 ºC = (Work. T
MAKE: CITY (ISO 9001 – 2015 CERTIFIED CO.)
Technical Specifications:
Maximum Temp.:
Zone 1 = 1200 ºC= (Work. Temp. = 1150 ºC, Heating Elements Silicon Carbide Rods with R type sensor)
Zone 2 = 1200 ºC = (Work. Temp. = 1150 ºC Heating elements Kanthal – A1 wire, Coil type with end connections with k type sensor)
Zone 3 = 1200 ºC = (Work. Temp. = 1150 ºC Heating elements Kanthal – A1 wire, Coil type with end connections with k type sensor.
Each Hot Zone Size = 200 mm
Temp. Accuracy: ± 1ºC
Inner Chamber:Ceramic Refractory / Board
Insulation: Ceramic Fibre
Construction: Split Type (Horizontal)
Body: Made of mild steel duly Powder Coated
Max. Tube Size to be accommodated: Inner Dia. = 60 Outer = 65 mm
Power Control: SSR unit,
Temp. Control: Microprocessor based PID Digital Set Point Controller individual for each Zone. Dual display of Set & Actual Temp. with soft touch keys.
With Thermocouple break protection & Cold junction compensation.
CE mark to meet EMC regulations
Sensor: Cr / Al for each Zone
Safety: Over current and Short Circuit Protection.
Thermocouple break alarm High Temp. alarm
Power Supply: 220 volts, single phase AC supply.
Safety: Over current and Short Circuit Protection Thermocouple break alarm. High Temp. alarm.
Industrial Three Zone Tube Furnace
Industrial Three Zone Tube Furnace
Industrial Three Zone Tube Furnace
: CITY (ISO 9001 – 2015 CERTIFIED CO.)
Technical Specifications:
Maximum Temp.:
Zone 1 = 1400 ºC= (Work. Temp. = 1350 ºC, Heating Elements MAKESilicon Carbide Rods with R type sensor)
Zone 2 = 1400 ºC = (Work. Temp. = 1350 ºC Heating Elements Silicon
Carbide Rods with R type sensor
Zone 3 = 1400 ºC = (Work. Temp. = 1350 ºC Heating elements
: CITY (ISO 9001 – 2015 CERTIFIED CO.)
Technical Specifications:
Maximum Temp.:
Zone 1 = 1400 ºC= (Work. Temp. = 1350 ºC, Heating Elements MAKESilicon Carbide Rods with R type sensor)
Zone 2 = 1400 ºC = (Work. Temp. = 1350 ºC Heating Elements Silicon
Carbide Rods with R type sensor
Zone 3 = 1400 ºC = (Work. Temp. = 1350 ºC Heating elements Silicon Carbide Rods with R type sensor
Each Hot Zone Size = 200 mm
Temp. Accuracy: ± 1ºC
Inner Chamber: CeramicCeramic Refractory / Board
Insulation: Ceramic Fibre
Construction: Split Type (Horizontal)
Body: Made of mild steel duly Powder Coated
Max. Tube Size to be accommodated: Inner Dia. = 200mm,Outer = 220 mm, Length: 1200mm
Power Control: : (Phase Angle Thyristor) with current limit and soft start facility and Step-Down Air-Cooled Transformer ,
Temp. Control: Microprocessor based PID Digital Set Point Controller individual for each Zone. Dual display of Set & Actual Temp. with soft touch keys.
With Thermocouple break protection & Cold junction compensation.
CE mark to meet EMC regulations
Sensor: Cr / Al for each Zone
Safety: Over current and Short Circuit Protection.
Thermocouple break alarm High Temp. alarm
Power Supply: 220 volts, single phase AC supply.
Safety: Over current and Short Circuit Protection Thermocouple break alarm. High Temp. alarm.
HOT AIR OVEN
Deluxe S.S. 304 Tube Furnace
Industrial Three Zone Tube Furnace
Maximum temperature: up to 250 C
Working Temp. Range: up to 250ºC. Temp. Accuracy: ± 1ºC.
In this system there is one path of circulating Hot Air in- between the inner chamber and insulation. Forced Air Moved by the motorized blower is called PERFECT SYSTEM. It results minimum temperature variation at any point in working space.
Temperature
Maximum temperature: up to 250 C
Working Temp. Range: up to 250ºC. Temp. Accuracy: ± 1ºC.
In this system there is one path of circulating Hot Air in- between the inner chamber and insulation. Forced Air Moved by the motorized blower is called PERFECT SYSTEM. It results minimum temperature variation at any point in working space.
Temperature controlled by based Microprocessor PID Digital Indicator Cum Controller from 50˚C to 250˚C with a sensitivity of ± 1˚C
Working chamber is made of SS 304 steel and outside made of Mild Steel finished with attractive powder coating with wire mesh nickel plated trays (2No.). To work on 220/230 Volts A.C.
OUTER SIZE
18” x 18” x 18” Inch.
note: size as per buyer requirement
Pellet Die 10mm
Deluxe S.S. 304 Tube Furnace
Deluxe S.S. 304 Tube Furnace
https://youtu.be/tENYv_FBTU8?si=v0iM7OMIE94gWVug
1) Die for 10mm Pellet Diameter with heating arrangement up to 250ºC with provision to control the temperature by thermostat .
Deluxe S.S. 304 Tube Furnace
Deluxe S.S. 304 Tube Furnace
Deluxe S.S. 304 Tube Furnace
Deluxe S.S. 304 Tube Furnace with base stand ➢ Tube Furnace is fully SS. 304 with Lazer Cutting body ➢ The base table is mild steel ➢ The hot zone of tube furnace is 300mm Total body of furnace is 400mm length ➢ The hight of tube furnace is 32 inch and base 8 inch panel total 40 inch with panel ➢ The tube is ID: 80, OD: 85, Length: 1200m
Deluxe S.S. 304 Tube Furnace with base stand ➢ Tube Furnace is fully SS. 304 with Lazer Cutting body ➢ The base table is mild steel ➢ The hot zone of tube furnace is 300mm Total body of furnace is 400mm length ➢ The hight of tube furnace is 32 inch and base 8 inch panel total 40 inch with panel ➢ The tube is ID: 80, OD: 85, Length: 1200mm, with S.S 304 coupler of gas parsing & vacuum nobe without pump & vacuum accessories also side stand of ms to support for both couplers ➢ Insulation of high purty & high temp. based Ceramic Board with kanthal A1 wire heating element . We don’t use glass wool board for insulation ➢ Extra thermocouple in side the tube for exact temp of furnace master Thermocouple is inside the tube ➢ Data recorder Unirac Model PPI with R 485 to view the set & actual temp. in bar graph Trend via pen drive
About Us
Split tube furnace/single zone/programmable/microprocessor
three zone tube furnace/ three zone splite tube furnace programmable/ microprocesser
two zone tube furnace/two zone splet tube furnace/programmable /microprocesser
- Model : CISTF (1700Prog. /1400Prog. /1200Prog.)
- Maximum Temp. : (1700°C/1400°C/1200°C)
- Working Temp. : (1600°C/1350°C/1150°C)
- Temp. Accuracy : ± 1ºC
- Heating Elements : Molybdenum Disilicide (MoSi2)
- Tube Size : as per customer require standard 60x65x1200mm Quds, 58x65x1200mm (alumina)
- Hot zone (200 to 250 to 300mm) standard other with as per cus
- Model : CISTF (1700Prog. /1400Prog. /1200Prog.)
- Maximum Temp. : (1700°C/1400°C/1200°C)
- Working Temp. : (1600°C/1350°C/1150°C)
- Temp. Accuracy : ± 1ºC
- Heating Elements : Molybdenum Disilicide (MoSi2)
- Tube Size : as per customer require standard 60x65x1200mm Quds, 58x65x1200mm (alumina)
- Hot zone (200 to 250 to 300mm) standard other with as per customer required hedry zone.
- Power Supply : 220 Volts, single phase AC supply.
- all accessories attachment as per customer required vacuum pump, quarts tube , alumina tube, high purity alumina tube (99.8%), chiller , MFC all tube of gases. vacuum thought rotary or refusion pump up to 10-4 bar rotation of tube, vertical, horizontal, all model and attachment
two zone tube furnace/two zone splet tube furnace/programmable /microprocesser
three zone tube furnace/ three zone splite tube furnace programmable/ microprocesser
two zone tube furnace/two zone splet tube furnace/programmable /microprocesser
- Model : CISTF (1700Prog. /1400Prog. /1200Prog.)
- Maximum Temp. : (1700°C/1400°C/1200°C)
- Working Temp. : (1600°C/1350°C/1150°C)
- Temp. Accuracy : ± 1ºC
- Heating Elements : Silicon Carbide
- Tube Size : as per customer require standard 60x65x1200mm Quds, 58x65x1200mm (alumina)
- Hot zone (200 to 250 to 300mm) standard other with as per customer requir
- Model : CISTF (1700Prog. /1400Prog. /1200Prog.)
- Maximum Temp. : (1700°C/1400°C/1200°C)
- Working Temp. : (1600°C/1350°C/1150°C)
- Temp. Accuracy : ± 1ºC
- Heating Elements : Silicon Carbide
- Tube Size : as per customer require standard 60x65x1200mm Quds, 58x65x1200mm (alumina)
- Hot zone (200 to 250 to 300mm) standard other with as per customer required hedry zone.
- Power Supply : 220 Volts, single phase AC supply.
- all accessories attachment as per customer required vacuum pump, quarts tube , alumina tube, high purity alumina tube (99.8%), chiller , MFC all tube of gases. vacuum thought rotary or refusion pump up to 10-4 bar rotation of tube, vertical, horizontal, all model and attachment
three zone tube furnace/ three zone splite tube furnace programmable/ microprocesser
three zone tube furnace/ three zone splite tube furnace programmable/ microprocesser
three zone tube furnace/ three zone splite tube furnace programmable/ microprocesser
- Model : CISTF (1700Prog. /1400Prog. /1200Prog.)
- Maximum Temp. : (1700°C/1400°C/1200°C)
- Working Temp. : (1600°C/1350°C/1150°C)
- Temp. Accuracy : ± 1ºC
- Heating Elements : KANTHAL “A1" .
- Tube Size :as per customer require standard 60x65x1200mm Quds, 58x65x1200mm (alumina)
- Hot zone (200 to 250 to 300mm) standard other with as per customer required
- Model : CISTF (1700Prog. /1400Prog. /1200Prog.)
- Maximum Temp. : (1700°C/1400°C/1200°C)
- Working Temp. : (1600°C/1350°C/1150°C)
- Temp. Accuracy : ± 1ºC
- Heating Elements : KANTHAL “A1" .
- Tube Size :as per customer require standard 60x65x1200mm Quds, 58x65x1200mm (alumina)
- Hot zone (200 to 250 to 300mm) standard other with as per customer required hedry zone.
- Power Supply : 220 Volts, single phase AC supply.
- all accessories attachment as per customer required vacuum pump, quarts tube , alumina tube, high purity alumina tube (99.8%), chiller , MFC all tube of gases. vacuum thought rotary or refusion pump up to 10-4 bar rotation of tube, vertical, horizontal, all model and attachment
industrial furnace
fully ss tempring forgingn MUFFLE FURNACE(PROGRAMMABLE)
three zone tube furnace/ three zone splite tube furnace programmable/ microprocesser
- Model : CISTF (1700Prog. /1400Prog. /1200Prog.)
- Maximum Temp. : (1700°C/1400°C/1200°C)
- Working Temp. : (1600°C/1350°C/1150°C)
- Temp. Accuracy : ± 1ºC
- Heating Elements : Molybdenum Disilicide (MoSi2) / Silicon Carbide / KANTHAL “A1" Wire.
- Tube Size : All size abilable as per customer required
- (Price without tube) Inner Chamber : Ceramic Brick
- Model : CISTF (1700Prog. /1400Prog. /1200Prog.)
- Maximum Temp. : (1700°C/1400°C/1200°C)
- Working Temp. : (1600°C/1350°C/1150°C)
- Temp. Accuracy : ± 1ºC
- Heating Elements : Molybdenum Disilicide (MoSi2) / Silicon Carbide / KANTHAL “A1" Wire.
- Tube Size : All size abilable as per customer required
- (Price without tube) Inner Chamber : Ceramic Brick/Board.
- Sensor : Pt / Pt - Rh
- Power Supply : 220 Volts, single phase AC supply. / 415 Volts, Three phase AC supply.
heatt treatment MUFFLE FURNACE
fully ss tempring forgingn MUFFLE FURNACE(PROGRAMMABLE)
fully ss tempring forgingn MUFFLE FURNACE(PROGRAMMABLE)
- Model : CIMF-17/Prog.
- Maximum Temp. : 1700ºC
- Working Temp. : 1600ºC
- Temp. Accuracy : ± 1ºC
- Heating Elements : Molybdenum Disilicide (MoSi2) heating elements, easily replaceable.
- Inner Chamber : Ceramic Brick/Board.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Body & Construction : Made of mild of steel duly Powder Coate
- Model : CIMF-17/Prog.
- Maximum Temp. : 1700ºC
- Working Temp. : 1600ºC
- Temp. Accuracy : ± 1ºC
- Heating Elements : Molybdenum Disilicide (MoSi2) heating elements, easily replaceable.
- Inner Chamber : Ceramic Brick/Board.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Body & Construction : Made of mild of steel duly Powder Coated/Triple Walled.
- Sensor : Pt / Pt - Rh
- Safety : High Speed Semi Conductor Fuse/Over Current Short Circuit Protection High Temp Alarm.
- Power Supply : 415 volts, 2/3 phase AC supply.
note: size as per buyer requirement
fully ss tempring forgingn MUFFLE FURNACE(PROGRAMMABLE)
fully ss tempring forgingn MUFFLE FURNACE(PROGRAMMABLE)
fully ss tempring forgingn MUFFLE FURNACE(PROGRAMMABLE)
- Model : CIMF-12/Prog.
- Maximum temperature : Upto 1200º C
- Working Temp. Range : Upto 1150º C.
- Temp. Accuracy : Heating Element are made of KANTHAL “A1" Wire.
- Inner Chamber : Ceramic Board/Fiber.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Model : CIMF-12/Prog.
- Maximum temperature : Upto 1200º C
- Working Temp. Range : Upto 1150º C.
- Temp. Accuracy : Heating Element are made of KANTHAL “A1" Wire.
- Inner Chamber : Ceramic Board/Fiber.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Body & Construction : Made of mild of steel duly Powder Coated/Double Walled.
- Sensor : Cr / Al
- Safety : High Speed Semi Conductor Fuse/Over Current Short Circuit Protection High Temp Alarm
note: size as per buyer requirement
bottam loading MUFFLE FURNACE(PROGRAMMABLE)
bottam loading MUFFLE FURNACE(PROGRAMMABLE)
bottam loading MUFFLE FURNACE(PROGRAMMABLE)
- Model : CIMF-12/Prog.
- Maximum temperature : Upto 1200º C
- Working Temp. Range : Upto 1150º C.
- Temp. Accuracy : Heating Element are made of KANTHAL “A1" Wire.
- Inner Chamber : Ceramic Board/Fiber.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Model : CIMF-12/Prog.
- Maximum temperature : Upto 1200º C
- Working Temp. Range : Upto 1150º C.
- Temp. Accuracy : Heating Element are made of KANTHAL “A1" Wire.
- Inner Chamber : Ceramic Board/Fiber.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Body & Construction : Made of mild of steel duly Powder Coated/Double Walled.
- Sensor : Cr / Al
- Safety : High Speed Semi Conductor Fuse/Over Current Short Circuit Protection High Temp Alarm
tundish MUFFLE FURNACE(PROGRAMMABLE)
bottam loading MUFFLE FURNACE(PROGRAMMABLE)
bottam loading MUFFLE FURNACE(PROGRAMMABLE)
- Model : CIMF-12/Prog.
- Maximum temperature : Upto 500º C
- Working Temp. Range : Upto 450º C.
- Temp. Accuracy : Heating Element are made of KANTHAL “A1" Wire.
- Inner Chamber : Ceramic Board/Fiber.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Body & Construction : Made of mild of steel duly Powder Coated/Double Walled.
- S
- Model : CIMF-12/Prog.
- Maximum temperature : Upto 500º C
- Working Temp. Range : Upto 450º C.
- Temp. Accuracy : Heating Element are made of KANTHAL “A1" Wire.
- Inner Chamber : Ceramic Board/Fiber.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Body & Construction : Made of mild of steel duly Powder Coated/Double Walled.
- Sensor : Cr / Al
- Safety : High Speed Semi Conductor Fuse/Over Current Short Circuit Protection High Temp Alarm
VERTICAL MUFFLE FURNACE(PROGRAMMABLE)
bottam loading MUFFLE FURNACE(PROGRAMMABLE)
VERTICAL MUFFLE FURNACE(PROGRAMMABLE)
- Model : CIMF-12/Prog.
- Maximum temperature : Upto 500º C
- Working Temp. Range : Upto 450º C.
- Temp. Accuracy : Heating Element are made of KANTHAL “A1" Wire.
- Inner Chamber : Ceramic Board/Fiber.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Body & Construction : Made of mild of steel duly Powder Coated/Double Walled.
- S
- Model : CIMF-12/Prog.
- Maximum temperature : Upto 500º C
- Working Temp. Range : Upto 450º C.
- Temp. Accuracy : Heating Element are made of KANTHAL “A1" Wire.
- Inner Chamber : Ceramic Board/Fiber.
- Insulation : Ultra High purity alumina low thermal mass insulation.
- Body & Construction : Made of mild of steel duly Powder Coated/Double Walled.
- Sensor : Cr / Al
- Safety : High Speed Semi Conductor Fuse/Over Current Short Circuit Protection High Temp Alarm
WATER CIRCULATING CHILLER
high pressure autoclave with staring & heating
high pressure autoclave with staring & heating
WATER CIRCULATING CHILLER
MAKE: CITY INSTRUMENTS
(An ISO, CE, NSIC, MSME, GEM, Trade Mark, IEC Certified Company)
Features: Convenient to use on table or floor. External Circulation function with powerful circulation pump with contact parts of stainless steel / brass. Control the temp. with PID temp. controller. Excellent safety with he
WATER CIRCULATING CHILLER
MAKE: CITY INSTRUMENTS
(An ISO, CE, NSIC, MSME, GEM, Trade Mark, IEC Certified Company)
Features: Convenient to use on table or floor. External Circulation function with powerful circulation pump with contact parts of stainless steel / brass. Control the temp. with PID temp. controller. Excellent safety with heater cuts off on overheating Separate power switches for both functions of Cooling and Circulation of liquid. Low noise level for the operation in a sealed space.
Bath volume (Lt.) 12 Lt. .
Temp. Set Range -10 ºC Ambient
Accuracy ±0.2ºC
Resolution 0.1ºC
Controller PID Microprocessor Controller
Materia - Bath - Stainless steel SS304
External Mild Steel duly Powder Coated
Insulation Polyurethane foam
Refrigerant CFC Free
Refrigerator(watt) 400W
Electric requirement &power consumption 220V AC 50Hz, Single phase
high pressure autoclave with staring & heating
high pressure autoclave with staring & heating
high pressure autoclave with staring & heating
WATER CIRCULATING CHILLER
MAKE: CITY INSTRUMENTS
(An ISO, CE, NSIC, MSME, GEM, Trade Mark, IEC
Technical Specification: -
Safe Temperature: 200°C
Max Operating Temp.: 200°C
Working Pressure: ≤ 20 Bar
In this system one temperature sensor and string beat in the sample inside the PTFE Teflon beaker. The maximum starring is 2000 RPM.
The Tempe
WATER CIRCULATING CHILLER
MAKE: CITY INSTRUMENTS
(An ISO, CE, NSIC, MSME, GEM, Trade Mark, IEC
Technical Specification: -
Safe Temperature: 200°C
Max Operating Temp.: 200°C
Working Pressure: ≤ 20 Bar
In this system one temperature sensor and string beat in the sample inside the PTFE Teflon beaker. The maximum starring is 2000 RPM.
The Temperature is controlled by hot plate with probe PT 100 sensor in this unit .The sample got uniform heating & starring with this setup.
Shell made of high-quality stainless steel.
Inner Shell - PTFE liner USE VERGIN PTEF IMPORTANT TEFLON BEAKER IN SIDE
Hydrothermal autoclave made from solid S. S high grade (no welding) with PTFE (liner with double cut cap maximum temp.200 degrees pressure design 20 bar disc mounting bomb fixture and suitable spares with split clamps for sealing body and heat. including nickel and polished of all S.S parts.
The design is fully suitable for high pressure and temp.
Capacity: 2 Ltr.
Aluminum Melting Furnace
high pressure autoclave with staring & heating
Aluminum Melting Furnace
MAKE: CITY INSTRUMENTS
(An ISO, CE, NSIC, MSME, GEM, Trade Mark, IEC
Technical Specification: -
Maximum temperature: up to 1200˚C
Working Temp. Range : up to 1100ºC.
Temp. Accuracy: ± 1ºC.
Light weight with ceramic Fibre wool insulation (instead of Brick insulation). The outer casing is made of double walled thick P.C.R.C. sheet, finishe
MAKE: CITY INSTRUMENTS
(An ISO, CE, NSIC, MSME, GEM, Trade Mark, IEC
Technical Specification: -
Maximum temperature: up to 1200˚C
Working Temp. Range : up to 1100ºC.
Temp. Accuracy: ± 1ºC.
Light weight with ceramic Fibre wool insulation (instead of Brick insulation). The outer casing is made of double walled thick P.C.R.C. sheet, finished with attractive powder coating.
Elements are made of KANTHAL “A-1” wire in coil form placed in the ribs of the tiles to have a free radiating heating. Backed by Zirconia cerewool insulation, which avoids loss of energy, this arrangement also assures the most uniform distribution of heat.
The weight & size of furnace is of one quarter and 30% respectively as compare to Bricks Furnace. A viewing cap is also provided on the door.
Temperature of the furnace is controlled by microprocessor based Programmable controller (1x14 segment, dwell, hold, ramp, timer all with Also provide calibration report of controller by NRL lab if requirement by costumer, with soft touch keypad and dual display of process & set temperature. The overshoot & undershoot of temp. Variation is drastically reduced compared to normal ON / OFF type-controlled furnace.
To work on 220/230 Volts A. C. Single Phase supply.
INNER MUFFLE SIZE:
W x H x D
150mm x 150mm x 300mm
(18”x 18”x18”) Inch
note: size as per buyer requirement
.
About Us
HIGH PRESSURE AUTOCLAVE WITH HEATING AND STARING (capt.100ml)
HYDROTHERMAL AUTOCLAVE WITH PTFE BEAKER ( capt. 5ml - 250ml)
HYDROTHERMAL AUTOCLAVE WITH PTFE BEAKER ( capt. 5ml - 250ml)
- Model : CIHPA-200
- Maximum Temp. : 200°C
- Working Temp. : 200°C
- Heating and Cooling Rate : ≤5°C/min
- Working Pressure : Max 10 MPa
- Material : Shell made of High-Grade stainless steel
- Inner Shell : PTFE Double Locking
HYDROTHERMAL AUTOCLAVE WITH PTFE BEAKER ( capt. 5ml - 250ml)
HYDROTHERMAL AUTOCLAVE WITH PTFE BEAKER ( capt. 5ml - 250ml)
HYDROTHERMAL AUTOCLAVE WITH PTFE BEAKER ( capt. 5ml - 250ml)
- Model : CIHA-260
- Maximum Temp. : 260°C
- Working Temp. : 260°C
- Heating and Cooling Rate : ≤5°C/min
- Working Pressure : Max 10 MPa
- Material : Shell made of High-Grade stainless steel
- Inner Shell : PTFE Double Locking
- Safety Features : Triple Locking System
HYDROTHERMAL AUTOCLAVE WITH HASTELLOY METRIAL (capt. 5ml - 250ml)
HYDROTHERMAL AUTOCLAVE WITH PTFE BEAKER ( capt. 5ml - 250ml)
HYDROTHERMAL AUTOCLAVE WITH HASTELLOY METRIAL (capt. 5ml - 250ml)
- Model : CIHPA-600
- Maximum Temp. : 600°C
- Working Temp. : 600°C
- Heating and Cooling Rate : ≤5°C/min
- Working Pressure : Max 10 MPa
- Material : HASTELLOY METRIAL
- Inner Shell : PTFE Double Locking
HYDROTHERMAL AUTOCLAVE WITH STAND
HYDROTHERMAL AUTOCLAVE (capt. 500ml to 200ml)
HYDROTHERMAL AUTOCLAVE WITH HASTELLOY METRIAL (capt. 5ml - 250ml)
- Model : CIHPA-200
- Maximum Temp. : 200°C
- Working Temp. : 200°C
- Heating and Cooling Rate : ≤5°C/min
- Working Pressure : Max 10 MPa
- Material : Shell made of High-Grade stainless steel
- Inner Shell : PTFE Double Locking
HYDROTHERMAL AUTOCLAVE (capt. 500ml to 200ml)
HYDROTHERMAL AUTOCLAVE (capt. 500ml to 200ml)
HYDROTHERMAL AUTOCLAVE (capt. 500ml to 200ml)
- Model : CIHPA-260
- Maximum Temp. : 260°C
- Working Temp. : 260°C
- Heating and Cooling Rate : ≤5°C/min
- Working Pressure : Max 10 MPa
- Material : Shell made of High-Grade stainless steel
- Inner Shell : PTFE Double Locking
spin coating unit programmble 10000 rpm
HYDROTHERMAL AUTOCLAVE (capt. 500ml to 200ml)
HYDROTHERMAL AUTOCLAVE (capt. 500ml to 200ml)
MODEL : CISP/Prog.
Stainless Steel bowl (removable), size 6 inch die, with acrylic cover. 500 – 9999 RPM / Speed Control / Digital Speed Indicator / Vacuum Dial gauge. Solenoid Vacuum release switch / Digital Timer 1 to 999 sec. Vacuum chuck to hold substrate form 1” to 4” inch dia Lid cover of acrylic with interlock saf
MODEL : CISP/Prog.
Stainless Steel bowl (removable), size 6 inch die, with acrylic cover. 500 – 9999 RPM / Speed Control / Digital Speed Indicator / Vacuum Dial gauge. Solenoid Vacuum release switch / Digital Timer 1 to 999 sec. Vacuum chuck to hold substrate form 1” to 4” inch dia Lid cover of acrylic with interlock safety switch / Frame: Epoxy coated MS and Aluminum. Facility for interlocking with Vacuum Pump / Tubing for Vacuum. To operate on 230V ± 10%, 1 phase 50 Hz AC only.
Vacuum Pump: Direct Drive, double stage rotary vacuum pump. Motor 1/4 HP Max. Vacuum = 730 mm Hg=97.33 kPa=30 torr
VACUUM PUMP
HIGH PRESSURE AUTOCLAVE
HIGH PRESSURE AUTOCLAVE
MAKE : CITY (ISO 9001: 2015 CERTIFIED CO.).
DOUBLE STAGE
'CITY' Double stage Rotary High Vacuum Pumps are mounted on fabricated M.S. Base Plate and complete with V-Belt drive and suitable for single or three phase electric motors.
Two stage Vacuum pumps are necessary for the lowest pressure (High Vacuum) and will generally give a swifter p
MAKE : CITY (ISO 9001: 2015 CERTIFIED CO.).
DOUBLE STAGE
'CITY' Double stage Rotary High Vacuum Pumps are mounted on fabricated M.S. Base Plate and complete with V-Belt drive and suitable for single or three phase electric motors.
Two stage Vacuum pumps are necessary for the lowest pressure (High Vacuum) and will generally give a swifter pump down time to intermediate pressure.
Ultimate Vacuum 0.001 mm Hg. Column (McLeod Gauge) on first oil filling.
HIGH PRESSURE AUTOCLAVE
HIGH PRESSURE AUTOCLAVE
HIGH PRESSURE AUTOCLAVE
- Model : CIHPA-200
- Maximum Temp. : 200°C
- Working Temp. : 200°C
- Heating and Cooling Rate : ≤5°C/min
- Working Pressure : Max 10 MPa
- Material : Shell made of High-Grade stainless steel
- Inner Shell : PTFE Double Locking
vacuum oven(round))
HIGH PRESSURE AUTOCLAVE
vertical tube furnace
- Model : CIVO-250 Prog.
- Temp. Range : Ambient to 250°C
- Temp. Accuracy : ± 1ºC
- Power Supply : 220 Volts, single phase AC supply.
Vacuum pump, double stage rotary, oil filled. Capacity = 75lt/ min, Motor 0.5 HP, with solenoid valve
vertical tube furnace
vacuum oven(rectangular )
vertical tube furnace
- Model CIVSTF (1700Prog. /1400Prog. /1200Prog.)
- Maximum Temp. : (1700°C/1400°C/1200°C)
- Working Temp. : (1600°C/1350°C/1150°C)
- Temp. Accuracy : ± 1ºC
- Heating Elements : Molybdenum Disilicide (MoSi2) / Silicon Carbide / KANTHAL “A1" Wire
- Tube Size : as per customer require standard 60x65x1200mm Quds, 58x65x1200mm (alumina)
- Hot zone (200 to
- Model CIVSTF (1700Prog. /1400Prog. /1200Prog.)
- Maximum Temp. : (1700°C/1400°C/1200°C)
- Working Temp. : (1600°C/1350°C/1150°C)
- Temp. Accuracy : ± 1ºC
- Heating Elements : Molybdenum Disilicide (MoSi2) / Silicon Carbide / KANTHAL “A1" Wire
- Tube Size : as per customer require standard 60x65x1200mm Quds, 58x65x1200mm (alumina)
- Hot zone (200 to 250 to 300mm) standard other with as per customer required hedry zone.
- Power Supply : 220 Volts, single phase AC supply.
- all accessories attachment as per customer required vacuum pump, quarts tube , alumina tube, high purity alumina tube (99.8%), chiller , MFC all tube of gases. vacuum thought rotary or refusion pump up to 10-4 bar rotation of tube, vertical, horizontal, all model and attachment
vacuum oven(rectangular )
vacuum oven(rectangular )
vacuum oven(rectangular )
- Model : CIVO-250 Prog.
- Temp. Range : Ambient to 250°C
- Temp. Accuracy : ± 1ºC
- Power Supply : 220 Volts, single phase AC supply.
Vacuum pump, double stage rotary, oil filled. Capacity = 75lt/ min, Motor 0.5 HP, with solenoid valve
HOT AIR OVEN
vacuum oven(rectangular )
vacuum oven(rectangular )
- Temperature range :Ambient +5°C to 300°C
- Temperature accuracy: +1°C or better
- Temperature sensor: RTD Pt100
- Temperature controller: PID temperature controller Display of SV & PV
- Construction: Double walled
- Inner chamber: Stainless steel 304
- Exterior : Powder coated GI sheet
- Insulation: Ceramic Wool
- Shelves : Chrome plated wire mesh cable t
- Temperature range :Ambient +5°C to 300°C
- Temperature accuracy: +1°C or better
- Temperature sensor: RTD Pt100
- Temperature controller: PID temperature controller Display of SV & PV
- Construction: Double walled
- Inner chamber: Stainless steel 304
- Exterior : Powder coated GI sheet
- Insulation: Ceramic Wool
- Shelves : Chrome plated wire mesh cable trays (removable)
- Door : Insulated solid door with spring latch
- Door gasket : Silicone Gasket
- Air circulation : Motor driven blower assembly
- Safety : Over temperature thermostat
- Power supply
: 220 Volts / 50 Hz
